MIL-PRF-19500/548H
* TABLE I. Group A inspection - Continued.
MIL-STD-750
Limit
Symbol
Unit
Inspection 1/ 2/
Method
Conditions
Min
Max
Subgroup 2 2/ - Continued
Coupler characteristics:
VCE = 5 V dc, IF = 1 mA dc
IC(ON)1
On-state collector current
3041
phototransistor mode:
4N47, 4N47A, 4N47U, 4N47BU
0.5
mA dc
4N48, 4N48A, 4N48U, 4N48BU
1.0
5.0
mA dc
4N49, 4N49A, 4N49U, 4N49BU
2.0
10.0
mA dc
VCE = 5 V dc, IF = 10 mA dc
IC(ON)2
All types
3041
5.0
mA dc
VCE(SAT)
Collector to emitter saturation
voltage
IC = 0.5 mA dc, IF = 2 mA dc
4N47, 4N47A, 4N47U, 4N47BU
0.3
V dc
IC = 1 mA dc, IF = 2 mA dc
4N48, 4N48A, 4N48U, 4N48BU
0.3
V dc
IC = 2 mA dc, IF = 2 mA dc
4N49, 4N49A, 4N49U, 4N49BU
0.3
V dc
Subgroup 3 2/
High temperature operation
TA = +100°C
Transistor characteristics:
Off-state collector current
VCE = 20 V dc, IF = 0,
IC(OFF)2
phototransistor mode:
3041
100
µAdc
IB = 0, condition D (see 4.5.4)
Coupler characteristics:
3041
VCE = 5 V dc, IF = 2 mA dc
IC(ON)3
On-state collector current
phototransistor mode:
4N47, 4N47A, 4N47U, 4N47BU
0.5
mA dc
4N48, 4N48A, 4N48U, 4N48BU
1.0
mA dc
4N49, 4N49A, 4N49U, 4N49BU
2.0
mA dc
LED characteristics
IF = 10 mA dc (see 4.5.3)
VF2
forward voltage
4011
0.7
1.3
V dc
See footnotes at end of table.
13
