MIL-PRF-19500-572 Semiconductor Device, Diode, Light Emitting, Types 1N6493, 1N6494, 1N6495, 1N6500, 1N6501, And 1N6502, Jan And JantxThis specification covers the performance requirements for red, yellow, and green light-emitting diodes \(LED\). Two levels of product assurance are provided for each device type as specified in MIL–PRF–19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


. . .
MIL­PRF­19500/572C
TABLE II. Group E inspection (all quality levels) for qualification and requalification only.
Qualification
Inspection
inspection
Method
Conditions
Subgroup 1
n = 45, c = 0
100 cycles 0°C to 100°C
Thermal shock (glass
1056
strain)
500 cycles, ­65°C to +100°C
Temperature cycling
1051
Hermetic seal
1071
See subgroup 2 of table I herein.
Electrical measurement
Subgroup 2
Intermittent operating life
1037
10,000 cycles.
Electrical measurements
See subgroup 2 of table I herein.
Subgroups 4 and 5
Not applicable
Subgroup 6
n = 11, c = 0
ESD
1020
Subgroups 7, 8, and 9
Not applicable
9
