MIL-PRF-19500-572 Semiconductor Device, Diode, Light Emitting, Types 1N6493, 1N6494, 1N6495, 1N6500, 1N6501, And 1N6502, Jan And JantxThis specification covers the performance requirements for red, yellow, and green light-emitting diodes \(LED\). Two levels of product assurance are provided for each device type as specified in MIL┬ûPRF┬û19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14

MIL�PRF�19500/572C

Dimensions

Ltr

Inches

Millimeters

Notes

Min

Max

Min

Max

.003

.005

0.08

0.13

.312

.328

7.92

8.33

.385

.445

9.78

11.30

BL1

.123

.127

3.12

3.23

.093

.099

2.36

2.51

.045

1.14

Nominal

.300 BSC

7.62 BSC

.015

.045

0.38

1.14

.018

.022

0.46

0.56

.125

.145

3.17

3.68

.020

.022

0.51

0.56

∅M

.075

.082

1.90

2.08

NOTES:

Dimensions are in inches. Millimeters are given for general information only.

The front and back pins are recessed on the two sides to prevent shorting of an adjacent device.

The basic pin spacing is between centerlines.

In accordance with ASME Y14.5M, diameters are equivalent to Φx symbology.

FIGURE 2. Physical dimensions for types 1N6500, 1N6501, and 1N6502.
