INCHPOUND
The documentation and process conversion
measures necessary to comply with this revision
MILPRF19500/572C
shall be completed by 16 August 2011.
16 May 2011
SUPERSEDING
MILPRF19500/572B
30 October 1998
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, LIGHT EMITTING,
TYPES 1N6493, 1N6494, 1N6495, 1N6500, 1N6501, AND 1N6502,
JAN AND JANTX
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MILPRF19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for red, yellow, and green light-emitting
diodes (LED). Two levels of product assurance are provided for each device type as specified in MILPRF19500.
1.2 Physical dimensions. See figure 1 for 1N6493 through 1N6495 and figure 2 for 1N6500 through 1N6502.
1.3 Maximum ratings.
IF
IFM (1)
V(BR) (2)
PFM (3)
Top and Tstg
°C
mA dc
mA (pk)
V dc
mW (pk)
35
60
5
105
65 to +100
(1) Pulse width ≤ 0.5 ms, PFM(AV) ≤ PF.
(2) IR = 10 µA dc.
(3) Derate linearly from +25°C at 1.4 mW/°C.
1.4 Characteristics, radiometric (physical), and photometric (visual).
λV
IR
C
Type
Color
IF
IV
VF
at VR = 0 V
Θ = 0°
at VR = 3 V
µA dc
mA dc
mcd
V dc
nm
pF
Min
Max
1N6493, 1N6500
Red
20
1
3
595
695
1
100
1N6494, 1N6501
Yellow
20
1
3
570
595
1
100
1N6495, 1N6502
Green
25
0.8
3
525
580
1
100
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 432183990, or emailed to semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5980
