MIL-PRF-19500/486H
TABLE I. Group A inspection - Continued.
MIL-STD-750
Limit
Symbol
Unit
Inspection 1/ 2/
Method
Conditions
Min
Max
Subgroup 2 - Continued.
Coupler characteristics:
VCE = 5 V dc, IF = 10 mA dc
IC(ON)2
On-state collector current,
3041
phototransistor mode:
(see 4.5.6)
4N22, 4N22A, 4N22U
2.5
mA dc
4N23, 4N23A, 4N23U
6.0
mA dc
4N24, 4N24A, 4N24U
10.0
mA dc
Collector to emitter saturated
3041
IF = 20 mA dc; pulsed (see 4.5.1)
VCE(sat)
Voltage
4N22, 4N22A, 4N22U
0.3
V dc
IC = 2.5 mA dc
4N23, 4N23A, 4N23U
0.3
V dc
IC = 5 mA dc
4N24, 4N24A, 4N24U
0.3
V dc
IC = 10 mA dc
Subgroup 3
TA = +100°C
High temperature operation
VCE = 20 V dc, IF = 0, IB = 0,
IC(OFF)2
Transistor characteristics:
3041
bias condition D (see 4.5.4)
µAdc
Off-state collector current
100
phototransistor mode:
VCE = 5 V dc, IF = 10 mA dc
IC(ON)3
Coupler characteristics:
3041
(see 4.5.6)
On-state collector current
phototransistor mode:
4N22, 4N22A, 4N22U
1.0
mA dc
4N23, 4N23A, 4N23U
2.5
mA dc
4N24, 4N24A, 4N24U
4.0
mA dc
IF = 10 mA dc (see 4.5.3)
VF2
LED characteristics:
Forward voltage
4011
0.7
1.3
V dc
