MIL-PRF-19500-520 Light Emitting Diode, Yellow, Jedec Types Jan1N6093, Jantx1N6093 \(Diffused Lens\), Jan1N6610, Jantx1N6610 \(Clear Lens\),And Panel Mount Assembly,Types Janm19500/52001, Jantxm19500/52002 \(Diffused Lens\), Janm19500/52003 And Jantxm19500/52004 \(Clear Lens\)This specification covers the performance requirements for hermetically-sealed yellow discrete and panel mount light emitting diodes. Two levels of product assurance are provided for each device type as specified in MIL–PRF–19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


. .
MIL­PRF­19500/520E
Dimensions
Dimensions
LTR
LTR
Inches
Millimeters
Inches
Millimeters
Min
Max
Min
Max
Min
Max
Min
Max
BD
.176
.190
4.47
4.83
J
.032
.042
0.81
1.07
.200
.220
5.08
5.59
LD
.016
.019
0.41
0.48
BD1
BH
.180
.225
4.57
5.72
LL
.970
1.030
24.64
26.16
H
.035
.045
0.89
1.14
PS
.045
.055
1.14
1.40
HT
.013
.024
0.33
0.61
NOTES:
1.
Dimensions are in inches. Millimeters are given for general information only.
2.
Cathode lead; both leads isolated from case.
3.
Glass/metal hermetic can.
Colored lens or clear glass lens (see 6.2).
4.
5.
For sunlight viewable LEDs, dimension BH is .213 inch (5.41 mm) minimum and .260 inch (6.60 mm)
maximum (see 6.2).
In accordance with ASME Y14.5M, diameters are equivalent to Φx symbology.
6.
FIGURE 1. Physical dimensions for types JAN1N6093, JANTX1N6093, JAN1N6610, and JANTX1N6610.
