INCHPOUND
The documentation and process conversion
measures necessary to comply with this revision
MILPRF19500/520E
shall be completed by 20 June 2014.
20 December 2013
SUPERSEDING
MILPRF19500/520D
1 May 2007
PERFORMANCE SPECIFICATION SHEET
LIGHT EMITTING DIODE, YELLOW, JEDEC TYPES JAN1N6093, JANTX1N6093 (DIFFUSED LENS),
JAN1N6610, JANTX1N6610 (CLEAR LENS), AND PANEL MOUNT ASSEMBLY,
TYPES JANM19500/52001, JANTXM19500/52002 (DIFFUSED LENS),
JANM19500/52003 AND JANTXM19500/52004 (CLEAR LENS)
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MILPRF19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for hermetically-sealed yellow discrete and
panel mount light emitting diodes. Two levels of product assurance are provided for each device type as specified in
1.2 Physical dimensions. The device package styles are as follows: TO46 in accordance with figure 1 and panel
mount assembly in accordance with figure 2.
1.3 Maximum ratings.
IF
IP (1)
Iptr (2)
V(BR) (3)
PFM (4)
TOP and TSTG
°C
mA dc
mA (pk)
A (pk)
V dc
mW (pk)
35
60
1.0
5
120
65 to +100
(1)
Pulse width maximum 0.5 ms and PFM(AV) less than PF.
Iptr = 1 µs pulse width, 300 pulses per second (pps).
(2)
IR = 10 µA dc.
(3)
Derate linearly from +50°C at 2.4 mW/°C.
(4)
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to semiconductor@dla.mil. Sine contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil.
AMSC N/A
FSC 5980
