MILDTL28803/2B
TABLE IV. Code letters for number, type and arrangements of modules.
Code letter
Number of modules
Type of module and arrangement
A
3 module assembly
All 7 segment modules
B
4 module assembly
All 7 segment modules
C
5 module assembly
All 7 segment modules
D
6 module assembly
All 7 segment modules
E
7 module assembly
All 7 segment modules
F
8 module assembly
All 7 segment modules
G
9 module assembly
All 7 segment modules
H
10 module assembly
All 7 segment modules
J
3 module assembly
One 4 segment followed by two
7 segments
K
4 module assembly
One 4 segment followed by three
7 segments
L
5 module assembly
One 4 segment followed by four
7 segments
M
6 module assembly
One 4 segment followed by five
7 segments
N
7 module assembly
One 4 segment followed by six
7 segments
P
8 module assembly
One 4 segment followed by seven 7 segments
Q
9 module assembly
One 4 segment followed by eight
7 segments
R
10 module assembly
One 4 segment followed by nine
7 segments
TABLE V. Code letters for color and luminance combinations.
2100° Kelvin limits
Code
Color
Luminance value in
of chromaticity
foot-lamberts (Candela/m2)
letter
minimum
X
Y
A
White
1/
1/
300 (1027.9)
B
Red
.695
.285
.703
SL 2/
50 (171.3)
.655
.325
SL 2/
.660
C
Green
.260
.570
.335
SL 2/
25 (85.6)
.018
SL 2/
D
Yellow
.562
.415
.570
SL 2/
200 (685.3)
.596
.382
.605
SL 2/
1/
Unfiltered, incandescent light.
2/
SL-Spectrum locus (where intersected by other coordinates pair).
7
