MILDTL28803/2B
FIGURE 5. Truth table letter assignments for seven segment alpha numeric display with decimal point.
TABLE III. Truth table for a four segment sign display with decimal point (direct wired).
Input
Δ = Segment lit
Display
DPT
B
C
E
F
B
C
E
F
DPT
O
O
O
O
Δ
Δ
Δ
Δ
O
O
Δ
Δ
O
Δ
ˇ
FIGURE 6. Truth table letter assignments for four segment sign display with decimal point.
5
