MILDTL28803/1E
NOTES:
1. Dimensions are in inches. Millimeter equivalents are given for general information only.
2. Unless otherwise specified, tolerances are ±.02 inch (0.51 mm) for two place decimals and
±.010 inch (0.25 mm) for three place decimals.
3. Design configuration optional within envelope as shown.
4. The values for dimensions A, B, C, D, and F are listed in table I. The depth of the mounting plate
(dimension E) is listed in table II.
5. Dimension F is for immersion seal displays only.
6. The two center mounting holes (located by dimension F) are required in designated immersion
seal displays only.
FIGURE 1. Type R01 display and panel cutout Continued.
TABLE I. Display assembly dimensions. 1/ 2/ 3/
Number of
Dimensions
Weight
modules
maximum
A
B
C
D
F 4/
per assembly
1
.62 (15.7)
1.187 (30.15)
.867 (22.02)
.67 (17.0)
---
3.5 (99.2)
2
1.12 (28.4)
1.687 (42.85)
1.367 (34.72)
1.17 (29.7)
---
5.0 (141.7)
3
1.62 (41.1)
2.187 (55.55)
1.867 (47.42)
1.67 (42.4)
---
7.0 (198.4)
4
2.12 (53.8)
2.687 (68.25)
2.367 (60.12)
2.17 (55.1)
---
8.5 (240.9)
5
2.62 (66.5)
3.187 (80.95)
2.867 (72.82)
2.67 (67.8)
1.433 (36.40)
10.5 (297.7)
6
3.12 (79.2)
3.687 (93.65)
3.367 (85.52)
3.17 (80.5)
1.683 (42.75)
12.0 (340.2)
7
3.62 (91.9)
4.187 (106.35)
3.867 (98.22)
3.67 (93.2)
1.933 (49.10)
14.0 (396.9)
8
4.12 (104.6) 4.687 (119.05)
4.367 (110.92)
4.17 (105.9)
2.183 (55.45)
16.5 (467.8)
1/
Dimensions are in inches. Millimeter equivalents are given for general information only.
2/
Unless otherwise specified, tolerances are ±.02 inch (0.51 mm) for two place decimals and
±.010 inch (0.25 mm) for three place decimals.
3/
Weights are in ounces. Gram equivalents are given for general information only.
4/
Dimension F is for immersion seal readouts only.
TABLE II. Seal type dimension.
Seal type
Dimension E
Dripproof
.22 (5.6)
Immersion
.32 (8.1)
1/
Dimensions are in inches. Millimeter equivalents are given for general information only.
2/
Unless otherwise specified, tolerances are ±.02 inch (0.51 mm) for two place decimals and
±.010 inch (0.25 mm) for three place decimals.
2
